Basic Information

• Keyboard

  Tri-sensor Scaled Hammer Action Keyboard Ⅱ (Key Surface Finish: Simulated ebony and ivory keys)

• Number of Keys

  88

• Touch Response

  3 sensitivity levels, off

• Sound Source

  Multi-dimensional Morphing AiR

• Maximum Polyphony

  192

• Number of Tones

  22

• Built-in Songs

  60

• Demonstration Songs

  Song Expansion (User Songs): 10 songs (max.) Up to approximately 90 KB / song

• Lesson Function

  Part on/off (Part Select: Right hand, Left hand)

• Recorder

  [MIDI Recorder] 2 tracks, 1 song Approximately 5,000 notes total Real-time recording

• Pedal

  3 built-in pedals (damper, soft, sostenuto) Half-Damper Pedal Operation: Yes

• Speaker

  12 cm x 2, 2-Speaker

• Amplifiers

  8 W + 8 W

• Power Supply

  [AC Adaptor] AD-E12150LW (DC 12V)

• Power Consumption

  18W

• Dimensions

  1,417 x 432 x 821 mm (w/o music stand)

• Weight

  36.6 kg

• Color

  Black

• Included Accessories

  AC Adaptor (AD-A12150LW), Music Stand, Piano Bench

Key Features

• Acoustic Simulator

  Hammer Response Damper Resonance Damper Noise

• Effects

  Reverb (4 types) Chorus (4 types) Brilliance (-3 ~ 0 ~ +3) DSP (Preset for some tones)

• Layer/Split

  Yes

• Octave Shift

  -2 octaves ~ 0 ~ +2 octaves

• Transpose

  -12 semitones ~ 0 ~ +12 semitones

• Tuning Control

  A4 = 415.5 Hz ~ 440.0 Hz ~ 465.9 Hz

• Scales

  Equal temperament + 16 variations

• Metronome

  0 to 9 beats; tempo range: 20 to 255

Others

• Concert Play

  10 songs, Playback Mode: LISTEN, LESSON, PLAY, Controller: START, STOP

• Duet Mode

  Yes

• Others

  ・Auto Power Off ・Slide-type keyboard cover

Input/Output Terminals

• USB port

  Type B

• Connector for 3-pedal unit

  Yes

• PHONES/OUTPUT

  2 (Stereo standard jack) multi-use OUTPUT terminal

Extended Functions

• Connection to App

  Yes (Chordana Play for Piano)

• MIDI

  Yes (Using the USB port)
